Mining Equipment Wash & Treatment System

Integrated Wash & Treatment System for Heavy-Duty Mining & Construction Applications!

Reduce your environmental liabilities and get the power of a wash monitor with a fraction of the water usage!

Mining Demucking Pressure Washer

Integrating our demucking system with our clarifier
oil water separator system

We have developed a revolutionary mining and construction wash and treatment system by integrating our demucking system with our clarifier oil water separator system.

Using low flow pumps, moderate pressure and specialized nozzles, our robustly- designed demucker systems can quickly clean large haul trucks, steel tracked vehicles or any heavy equipment caked with mud, clay, ice, grass or muck – using only 60 gpm of water.

After washing, we can then process this water through our stainless steel clarifier oil water separator to reduce your environmental liabilities. Even though full of solids, oils and grease, our separator will effectively treat this wash water for re-use or discharge.

Fast and effective cleaning with low water treatment costs – definitely a win-win situation!

Demucker Features:

  • 20 to 60 GPM @ 500 to 1000 PSI
  • Stainless Steel Construction
  • Emergency Stop System
  • NEMA 4X Integrated Control Panel
  • High-Efficiency Diaphragm or Multi Stage Pumps
  • Trolley-mounted Multi-directional Stream-to-Cone Gun & Wand

Stainless Steel Clarifier Oil Water Separator

Stainless Steel Clarifier Oil Water Separator Features:

  • Advanced coalescing media designed to remove 99% of oil droplets
  • Inclined plates to remove solids
  • Sludge hopper to capture and contain settleable solids
  • Adjustable rotatable pipe oil skimmers
  • Electric or Air diaphragm transfer pump
  • Internal oil storage tank
  • Effluent compartment for pump out or gravity flow to sewer
Give us a call for more product information – 800-453-8639

Features withing an oil water separator and demucking sytem

Optional Features Available:

  • UL Listings
  • Remote Motor Controls
  • Heating Systems
  • VFD Systems
  • Automated Wash Monitors
  • Portable Wash Containment Pad
  • Industrial Grade Hose Reels and Stands

SYSTEM SPECIFICATIONS

MODEL MWT-20 MWT-60
Demucker
Max Flow Rate & Pressure 20 GPM @ 1000 PSI 60 GPM @ 1000 PSI
Uses Fresh or Recycled Water Both Both
Motor, HP 15 2 @ 15
Pump Type Electric Diaphragm Electric Diaphragm
Controls Manual/Remote/PLC Manual/Remote/PLC
Electric 120/208/480/575 V 3 PH 50/60 HZ 208/480/575 V 3 PH 50/60 HZ
Hose 75’ L @ ¾” D ¾”D, Length designed to Facility
Gun/Wand Handheld/Trolley-Mounted Stream-to-Cone

(Manual or Automated)

Trolley-mounted Multi-directional

Stream-to-Cone (Manual or Automated)

Approximate Dimensions 18” W x 60” L x 24” H



36” W x 60” L x 24” H



Stainless Steel Clarifier Oil Water Separator
Max Flow Rate 20 GPM 75 GPM
Internal Tank Capacity 650 Gallons 1420 Gallons
Sludge Capacity 27 Gallons 85 Gallons
Coalescing Media 6 Cubic Feet 24 Cubic Feet
Pump Type Air or Electric Diaphragm Air or Electric Diaphragm
Controls Air or Electric Manual/Remote/PLC Manual/Remote/PLC
Utilities 120/208/480/575 V 3 PH 50/60 HZ 120/208/480/575 V 3 PH 50/60 HZ
Available Options Ozone, Polishing Packs, Floating Skimming Assembly Ozone, Polishing Packs, Floating Skimming Assembly
Approximate Dimensions 8’ L x 3’ 6” W x 5’ 7” H 10’ L x 4’ 6”W x 6’ 10” H
